GoHunt Vertical Screw Conveyor is efficient for elevating a variety of bulk materials at very steep inclines or completely vertical. The compact design allows for the vertical screw loader to fit into almost any plant layout, maximizing efficiency while conserving space.
Key Features and Benefits
1. Space-Efficient Design: A space-efficient solution without compromising on performance.
2. Material Fabrication: Made of stainless steel and food-grade materials for durability and sanitation.
3. High-Powered Motor: 13 kW motor, 380 V, 50 Hz (other voltages available).
4. Variable Speed: Operating at speeds of 160 – 230 rpm for optimal material transfer.
5. Screw Tunnel Diameter: 377 mm for efficient handling of materials.
6. Compact Dimensions: Specs measuring 3230 x 1250 x 3720 mm.
1. Material Fabrication: Made of stainless steel and food-grade materials.
2. Motor: 13 kW, 380 V, 50 Hz (other voltages available).
3. Speed: Variable speed (160 – 230 rpm).
4. Diameter of Screw Tunnel: 377 mm.
5. Infeed Height: 800 mm.
6. Outfeed Height: 2300 mm (other specifications available upon request).
-
Vertical Screw Conveyor
